| FRAMESET |
| Frame |
Orbea Kemen Mid Bar, Shimano Steps, integrated battery, Hydroformed Alloy 6061, internal cable routing, Boost 148x12, carrier & kickstand compatible |
| Fork |
SR Suntour XCR34, 100 mm, Coil, Q15x110 |
| Steerer Tube |
FSA 1-1/2" Integrated Aluminium Cup |
| E-BIKE SYSTEM |
| Battery |
Orbea Internal 540 Wh (Optional 252 Wh Range Extender) |
| Range Extender |
N/A |
| Motor |
Shimano EP600 |
| Display |
N/A |
| Charger |
Orbea 2nd-Gen eBike Smart Charger, 42V / 2–4A |
| Remote |
EN600-L |
| DRIVETRAIN |
| Chainring |
Alloy 40T with chainguard |
| Crank |
Shimano Steps EM600 |
| Shifters |
Shimano CUES SL-U4000 |
| Cassette |
Shimano CS-LG300, 11–46T, 9-Speed |
| Rear Derailleur |
Shimano CUES U4000 GS Shadow |
| Chain |
KMC eGlide |
| COCKPIT |
| Handlebar |
Orbea Urban, Integrated Light, Rise 50, Width 760 |
| BRAKES |
| Brakes |
Shimano MT200 Hydraulic Disc |
| Brakes Configuration |
N/A |
| WHEELS |
| Wheels |
Alloy, Tubeless, 29", 29c, 32H |
| Tyres |
Schwalbe Johnny Watts LR, 60-622, reflective tape |
| ACCESSORIES |
| Pedals |
VP-537 Black |
| Front Carrier |
N/A |
| Rear Carrier |
Orbea RR-02 Alloy, MIK HD & MIK Side & Ortlieb QL3.1 compatible, max 30 kg |
| Carrier Accessories |
N/A |
| Mudguard |
Curana Apollo Orbit 70 mm |
| Front Position Light |
Orbea integrated, USB-C charging point |
| Front Light |
Supernova Starstream Pure, Low Beam |
| Rear Light |
Supernova TL3 Z |
| Kickstand |
Massload rear adjustable |
| COMPONENTS |
| Seatpost |
Alloy, 31.6 mm, Setback 0 |
| Saddle |
Selle Royal Vivo Ergo |
