| FRAMESET |
Frame
ACX Carbon Uci Approved, Internally Routed, Pressfit BB86, 12x142mm
Fork
Full Carbon, Taper 1-1/8" To 1-1/2", Flat Mount Disc Brake
|
| DRIVETRAIN |
Shift Levers
Shimano 105 Di2 ST-R7170, 2x12-Speed Dual Control Lever
Front Derailleur
Shimano 105 Di2 FD-R7150 Braze-On
Crankset
Shimano 105 FC-R7100
Chainrings
52/36T
Chain
KMC X-12
Cassette
Shimano 105 CS-R7101, 11-34T
Rear derailleur
Shimano 105 Di2 RD-R7150 Direct Attach
|
| BRAKES |
Front Brake
Shimano 105 BR-R7120 Hydraulic Disc, 160mm SM-RT70 Rotor, Center Lock
Rear Brake
Shimano 105 BR-R7100 Hydraulic Disc, 140mm SM-RT70 Rotor, Center Lock
|
| WHEELS |
Rims
Entity Alloy Double Wall, 30mm Depth, 19mm Inner, 24H, Tubeless Ready*
Front Hub
Novatec D791SB-CL, 12x100mm
Rear Hub
Novatec D792SB-CL-X12, 12x142mm
Tires
Schwalbe One, Addix, Raceguard, Microskin, 700x28C, Tubeless ready*
|
| CONTACT POINTS |
Handlebar
Entity Xpert Alloy, 31.8mm, 125mm Drop, 70mm Reach
Stem
Entity Xpert Alloy, 31.8mm, 10°
Seatpost
Entity Xpert Carbon, 27.2 x 350mm, 15mm, Integrated Shape W/ Bolt
Saddle
Entity Flux2, Cr-Mo Ø 7mm
Pedals
The bike is not supplied with pedals
|
