| FRAMESET |
Frame
ACX Carbon Uci Approved, Internally Routed, Pressfit BB86, 12x142mm
Fork
Full Carbon, Taper 1-1/8" To 1-1/2", Flat Mount Disc Brake
|
| DRIVETRAIN |
Shift Levers
Shimano Ultegra Di2 ST-R8170, 2x12-Speed Dual Control Lever
Front Derailleur
Shimano Ultegra Di2 FD-R8150 Braze-On
Crankset
Shimano Ultegra FC-R8100
Chainrings
50-34T or 52-36T
Chain
KMC X-12
Cassette
Shimano Ultegra CS-R8101, 11-34T
Rear derailleur
Shimano Ultegra Di2 RD-R8150 Direct Attach
|
| BRAKES |
Front Brake
Shimano Ultegra BR-R8170 Hydraulic Disc, 160mm RT-CL800 Rotor, Center Lock
Rear Brake
Shimano Ultegra BR-R8170 Hydraulic Disc, 140mm RT-CL800 Rotor, Center Lock
|
| WHEELS |
Rims
Novatec R3, Carbon, 38mm Depth, 15mm Inner, Tubeless Ready*
Front Hub
Novatec D791SB-CL, 12x100mm, Straight Pull Spokes, 24H
Rear Hub
Novatec D792SB-CL-X12, 12x142mm, Straight Pull Spokes, 24H
Tires
Schwalbe One, Addix, Raceguard, Microskin, 700x28C, Tubeless ready*
|
| CONTACT POINTS |
Handlebar
Entity Xpert Alloy, 31.8mm, 125mm Drop, 70mm Reach
Stem
Entity Xpert Alloy, 31.8mm, 10°
Seatpost
Entity Xpert Carbon, 27.2 x 350mm, 15mm, Integrated Shape W/ Bolt
Saddle
Entity Flux2, Cr-Mo Ø 7mm
Pedals
The bike is not supplied with pedals
|
